Description
African Energy modules are made by some of the world’s most sophisticated module manufacturers and are designed for Africa’s off-grid solar charging and water pumping needs. The modules include efficient crystalline cells set in a solid aluminum frame and feature TÜV and IEC certification. With a 30-year warranty, these modules can provide power for several generations – and the quality is assured by African Energy’s decade of experience in the solar industry.
Electrical Characteristics:
- Maximum Power at STC (Pmax) 620 W
- Optimum Operating Voltage (Vmp) 40.93 V
- Optimum Operating Current (Imp) 12.90 A
- Open Circuit Voltage (Voc) 48.40 V
- Short Circuit Current (Isc) 13.70 A
- Module Efficiency 22.95%
- Operating Module Temperature -40 °C to +85 °C
- Maximum System Voltage 1000/1500 V DC (IEC)
- Maximum Series Fuse Rating 20 A
- Power Tolerance 0/+5 %
- 30-year warranty
Mechanical Specifications:
- Solar Cells Monocrystalline 144 (72*2) pcs
- No. of Cells 144 (72*2)
- Dimensions 2278x1134x30mm
- Weight 28.3kg
- Front Glass High transparency solar glass 3.2mm
- Frame Black/Silver Anodized aluminum alloy
- Junction Box IP68 rated
- Output Cables 4.0 mm2, portrait: 300mm/300mm
- Connector MC4 Compatible
- Wind/Snow Load 2400pa/5400pa
Reviews
There are no reviews yet.
