DEYE 16 kW Single Phase 3 MPPT Hybrid Inverter

SKU SUN-16K-SG01LP1E Categories , Tag

Share this Product!


Higher yields / Safe & Reliable / Smart / User-friendly

SUN 12/14/16K-SG, a hybrid inverter, is suitable for residential and light commercial use, maximizing the self-consumption rate of solar energy and increasing your energy impendence.   During the day, the PV system generates electricity which will be provided to the loads initially. Then, the excess energy will charge the battery via SUN 12/14/16K-SG. Finally, the stored energy can be released when the loads require it. The battery can also be charged by the diesel generator to ensure uninterrupted supply in the event of grid blackout.

It is equipped with an RS485 / CAN port for battery communication.

Remotely shutdown function

Smart Monitoring Platform
Thanks to the smart monitoring platform, Deye full series inverter products support remote shutdown immediately when an accident occurs. Setting parameters and FW updates remotely makes PV plant O&M easier.

  • Colorful touch LCD, IP65 protection degree
  • 6 time periods for battery charging/discharging
  • Max. charging/discharging current of 290A.
  • Max.16pcs parallel
  • DC couple and AC couple to retrofit existing solar system.
  • Support storing energy from diesel generators.
  • 48V low voltage battery, safe and reliable
  • Unique Smart Load application and Grid peak shaving function
  • 4ms fast transfer from on-grid to off-grid mode, ensuring the non-inverter type air conditioner works well.

Technical Specifications

Model SUN-12K-SG01LP1-EU SUN-14K-SG01LP1-EU SUN-16K-SG01LP1-EU
Battery Input Data
Battery Type Lead-acid or Lithium-ion
Battery Voltage Range (V) 40~60V
Max. Charging Current (A) 220A 250A 290A
Max. Discharging Current (A) 220A 250A 290A
UPS Power (W)
12000 12000 12000
Charging Curve 3 Stages / Equalization
External Temperature Sensor Yes
Charging Strategy for Li-Ion Battery Self-adaption to BMS
PV String Input Data
Max. DC Input Power (W) 15600W 18200W 20800W
Max. DC Input Voltage (V)
Start-up Voltage (V)
MPPT Range (V) 150~425V
Rated DC Input Voltage (V)
PV Input Current (A) 26+26+26
Max. PV ISC (A) 44+44+44
No. of MPPT Trackers 3
No. of Strings Per MPPT Tracker 2
AC Output Data
Rated AC Output Power (W) 12000W 14000W 16000W
AC Output Rated Current (A) 52.2 60.9 69.6
Max. Continuous AC Passthrough (A)
Peak Power (off-grid) 2 times of rated power, 5 S
Power Factor 0.8 leading to 0.8 lagging.
Output Frequency and Voltage 50/60Hz; L/N/PE 220/230Vac (single phase)
Grid Type Single Phase
DC injection current (mA)
<0.5% 1n
Max. Efficiency 97.60%
Euro Efficiency 96.50%
MPPT Efficiency 99.90%
Certifications and Standards
Grid Regulation  CEI 0-21, VDE-AR-N 4105, NRS 097, IEC 62116, IEC 61727, G99, G98,

VDE 0126-1-1, RD 1699, C10-11
Safety EMC/Standard IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
General Data
Operating Temperature Range (℃) -45~60℃, >45℃ Derating
Cooling Smart cooling
Noise (dB) <30 dB
Communication with BMS RS485; CAN
Weight (kg) 48.5
Size (mm) 464W×798.4H×300D
Protection Degree IP65
Installation Style Wall-mounted
Warranty 5 years
