WECO 5K3 XP Dual Voltage Lithium Battery

SKU 5K3 XP Categories , Tag

The 5K3 XP is the most advanced Lithium Module for Home and Industrial Energy Storage systems. One product suitable for two applications LV and HV. Fast connections. Wall Mounted, floor mounted, Stackable, serial or parallel application. High Capacity thanks to expandible and simple configuration. Wireless monitoring for real time intervention and maintenance.

Share this Product!

Description

The 5K3 XP is the most advanced Lithium Module for Home and Industrial Energy Storage systems. One product suitable for two applications LV and HV. Fast connections. Wall Mounted, floor mounted, Stackable, serial or parallel application. High Capacity thanks to expandible and simple configuration. Wireless monitoring for real time intervention and maintenance.

LOW VOLTAGE AND HIGH VOLTAGE

SINGLE MODULE:

Battery System Capacity (kWh) 5.2
Single Module Nominal Voltage (V) 52
Application  Dual Voltage LV/HV
Expandability  HV Mode: Max 16 Modules in Series with Single HV Box = One HV Cluster
LV Mode: Max 8 Modules in Parallel without WeHub = One LV Cluster
Cluster Net Capacity  Max 144 Modules per HV System / Max 100 Modules per LV System
Voltage Range (V) 48.5 – 1000
Cell Capacity (Ah) 105
Usable Capacity (Ah)  100
Dimension (WxDxH mm) 580x463x156
Weight (Kg) 52
Charge / Discharge Current (A) 110
Step 01 160 (60 sec)
Peak 200 (Peak 5 sec)
DOD% (Up to)  100%
Communication Port RS485, CAN, 232, Wi-Fi
Single string quantity(pcs) 16
Discharge Temperature /°c* -20 ~ 55
Charge Temperature /°c* -10 ~ 55
Shelf Temperature/°c -10 ~ 50
Humidity 5%~95%
Altitude (m) <3000
Design life 15 Years (25°c)
Cycle Life >7000, 25°c
Authentication Level IEC62619/UL1973 CE/UN38.3
Features Pre-Charge+Fuse LV+ Fuse HV+ Auto Contactor + Dual BMS+ Multi BMS FW management
 Applicability for Low Voltage and High Voltage systems, four protections levels with HV BOX, real time balancing, Adaptive charge /discharge CAN logic, 3 steps adaptive charging logic, 2xDI/DO programmable, Mobile APP for monitoring and remote control, update, debug, data save.
