HUAWEI 20 kW Smart String Inverter

SKU SUN2000-20KTL-M2 Categories , Tag

Share this Product!

Description

HUAWEI Smart String Inverter SUN2000-20KTL-M2
Digital PV Solution for Upgraded Safety & Better Experience

  • Compatible to Huawei Smart PV Optimizer SUN2000-450W-P, enables more modules on rooftop.
  • Up to 30% higher yields contributed by optimizing each panel performance.
  • AI Powered AFCI to proactively mitigate fire risk.
  • Communication:
    – RS485
    – Ethernet via Smart Dongle-WLAN-FE (Optional)
    – 4G / 3G / 2G via Smart Dongle-4G (Optional)
  • Inverter with no quick wear parts, failure rate < 0.5%

Features:

  • Recommended max. PV input power: 30000 Wp
  • Max. input voltage: 1080 V
  • Number of MPP trackers / Input number per MPP tracker: 2 / 2
  • Rated output power: 20 kW
  • Rated output voltage: 220 Vac / 380 Vac, 230 Vac / 400 Vac, 3W + N + PE
  • Max. output current: 33,5 A
  • DC and AC surge protection: compatible with TYPE II protection class according to EN/IEC 61643-11
  • Cooling: Natural Convection
  • Display: LED Indicators; Integrated WLAN + FusionSolarApp
  • Degree of protection: IP65
  • Weight (with mounting plate): 25 kg
  • Dimension (W x H x D): 525 x 470 x 262 mm.
